| Wire sizes | | |
| Solid | 0.2 mm² - 4.0 mm² | |
| Stranded | 0.2 mm² - 4.0 mm² | |
| Stranded with ferrule | 0.2 mm² - 4.0 mm² | |
| Clamping range | 0.2 mm² - 4.0 mm² | |
| Dimensions | | |
| Stripped length | 9.0 mm | |
| Width | 6.0 mm | |
| Length | 58.5 mm | |
| Height TS35 x 7.5 | 60.0 mm | |
| Connections | | |
| Screw thread | M3 | |
| Screw head | Slot | |
| Torque | 0.5 - 1.0 Nm | |
| Plug gauge EN 60947-1 | A4 | |
| Insulating Material | | |
| Material | PA 6.6 | |
| Flammability class | UL 94 V-2 | |
| Temperature | | |
| Working temperature | -40 - 105 °C | |
| General | |
| Cross connection channels | 1 |
Just click on the image and it will open an enlarged view.
| Article Designation | Article Number | PU |
| SRD4-G-V-BEIGE | 417048.2 | 100 |
| SRD4-G-V-BLUE | 417048.5 | 100 |
| Colours | Order Data | | |
| BEIGE, similar RAL 1019 | 417048.2 | | |
| BLUE, similar RAL 5015 | 417048.5 | | |
| Article Designation | Order Data | PU |
| End Plate APG4 | 492586.2 | 20 |
| Cross-Connection uninsulated Q2 | 492087.0 | 50 |
| Cross-Connection uninsulated Q3 | 492088.0 | 50 |
| Cross-Connection uninsulated Q4 | 492089.0 | 20 |
| Cross-Connection uninsulated Q10 | 492090.0 | 10 |
| Endstützen ES35/K/ST | 492828.0 | 50 |
| Quick Labelling PSB6/50 | 494702.7 | 500 |
| Ratings |  | | |  | | |  |
| Rated voltage | | | | | | | 500 V |
| Rated current | | | | | | | 32 A |
| Rated wire size | AWG 22-12 | | | AWG 22-12 | | | 4.0 mm² |
| Rated impulse voltage | | | | | | | 6 kV |
| Pollution degree | | | | | | | 3 |
