| Wire sizes | | |
| Solid | 0.2 mm² - 4.0 mm² | |
| Stranded | 0.2 mm² - 4.0 mm² | |
| Stranded with ferrule | 0.2 mm² - 4.0 mm² | |
| Clamping range | 0.2 mm² - 4.0 mm² | |
| Dimensions | | |
| Stripped length | 9.0 mm | |
| Width | 8.0 mm | |
| Length | 67.0 mm | |
| Height TS35 x 7.5 | 55.5 mm | |
| Height TS32 | 60.0 mm | |
| Connections | | |
| Screw thread | M3 | |
| Screw head | Slot | |
| Torque | 0.5 - 1.0 Nm | |
| Plug gauge EN 60947-1 | A4 | |
| Insulating Material | | |
| Material | PA 6.6 | |
| Flammability class | UL 94 V-2 | |
| Temperature | | |
| Working temperature | -40 - 105 °C | |
| General | |
| Fuse size | 5x20,5x25 |
| Max. power loos on fuse | 1.6 W |
Just click on the image and it will open an enlarged view.
| Article Designation | Article Number | PU |
| SRSI4-P-BEIGE | 41079.2 | 100 |
| SRSI4-P-BLUE | 41079.5 | 100 |
| Colours | Order Data | | |
| BEIGE, similar RAL 1019 | 41079.2 | | |
| BLUE, similar RAL 5015 | 41079.5 | | |
| Article Designation | Order Data | PU |
| End Plate AP/SI-2 | 492186.2 | 50 |
| External Cross-Connector insulated AQI2/8/11 | 492067.0 | 50 |
| External Cross-Connector insulated AQI3/8/11 | 492068.0 | 50 |
| External Cross-Connector insulated AQI4/8/11 | 492069.0 | 50 |
| Kontakthülse KH5 | 492470.0 | 1 |
| Endstützen ES35/K/ST | 492828.0 | 50 |
| Quick Labelling PSB8/40 | 499323.7 | 400 |
| Ratings | | | |  |  | |  |
| Rated voltage | | | | 500 V | 600 V | | 500 V |
| Rated current | | | | 6.3 A | 16 A | | 6.3 A |
| Rated wire size | | | | AWG 22-12 | AWG 22-12 | | 4.0 mm² |
| Rated impulse voltage | | | | | | | 4 kV |
| Pollution degree | | | | | | | 3 |
