| Wire sizes | | |
| Solid | 0.5 mm² - 4.0 mm² | |
| Stranded | 0.5 mm² - 4.0 mm² | |
| Stranded with ferrule | 0.5 mm² - 2.5 mm² | |
| Dimensions | | |
| Width | 5.1 mm | |
| Length | 103.5 mm | |
| Height TS35 x 7.5 | 73.0 mm | |
| Connections | | |
| Plug gauge EN 60947-1 | A3 | |
| Insulating Material | | |
| Material | PA 6.6 | |
| Flammability class | UL 94 V-0 | |
| Temperature | | |
| Working temperature | -40 - 120 °C | |
Just click on the image and it will open an enlarged view.
| Article Designation | Article Number | PU |
| ZRMA2.5-BEIGE | 43582.2 | 50 |
| ZRMA2.5-BLUE | 43582.5 | 50 |
| Colours | Order Data | | |
| BEIGE, similar RAL 1019 | 43582.2 | | |
| BLUE, similar RAL 5015 | 43582.5 | | |
| Article Designation | Order Data | PU |
| End Plate ZAP-VMAK | 493762.2 | 20 |
| External Cross-Connector insulated AQI2/5/15 | 492023.0 | 50 |
| External Cross-Connector insulated AQI3/5/15 | 492024.0 | 50 |
| Four-Way Covers ZAD2.5/4/B | 493706.0 | 20 |
| Labelling Adapters ZBA3 | 493813.2 | 50 |
| Endstützen ZES35 | 493748.2 | 50 |
| Test Adapter ZTA2.5 | 493740.2 | 10 |
| Quick Labelling PSB5/50 | 494600.7 | 500 |
| Ratings | | | |  |  | |  |
| Rated voltage | | | | 300 V | 300 V | | 400 V |
| Rated current | | | | 15 A | 15 A | | 24 A |
| Rated wire size | | | | AWG 20-12 | AWG 20-12 | | 2.5 mm² |
| Rated impulse voltage | | | | | | | 6 kV |
| Pollution degree | | | | | | | 3 |
